Search results for: 'bolt lock'

Series: 1080

Included: 4 locks and 1 key with 17mm hex

Chrome & Black Finish (BK)

Chrome & Black Finish (BK)

Some sizes available in 19mm Hex (SP)

Some sizes available with 14mm radius seat

12mm Radius Seat

12mm Radius Seat

12mm Radius Seat

Chrome & Black Finish (BK)

Short Head available (SH)

Vehicle: 5 x 150mm
Wheel: 6 x 5.5" (139.7mm)

2" Thickness Only
14mm 1.5 studs

2 PC Adapter Attached with Allen Bolts

Ball Seat Lug Bolt - Black Finish
14mm 1.5 Threads
Thread Length: 1.77" (44.95mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.5 Threads
Thread Length: 1.97" (50mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.5 Threads
Thread Length: 2.36" (60mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 0.93" (23.6mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.10" (28mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.30" (33mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.55" (39.4mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.97" (50mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 2.17" (55.1mm)
17mm Socket

Ball Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 2.36" (60mm)
17mm Socket

Sku: 6208086

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 0.86" (21.9mm)
17mm Socket

Sku: 6208093

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 0.93" (23.6mm)
17mm Socket

Sku: 6208118

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.18" (30mm)
17mm Socket

Sku: 6208130

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.30" (33mm)
17mm Socket

Sku: 6208155

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.55" (39.4mm)
17mm Socket

Sku: 6208177

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.77" (45mm)
17mm Socket

Sku: 6208189

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.89" (48mm)
17mm Socket

Sku: 6208197

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.97" (50mm)
17mm Socket

Sku: 6208217

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 2.17" (55.1mm)
17mm Socket

Sku: 6208236

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 2.36" (60mm)
17mm Socket

Sku: 6208110

Cone Seat Lug Bolt
14mm 1.50 Threads
Thread Length: 1.10" (28mm)
17mm Socket

SKU: 6208086BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 0.86" (21.8mm)
17mm Socket

SKU: 6208093BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 0.93" (23.6mm)
17mm Socket

SKU: 6208110BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.10" (28mm)
17mm Socket

SKU: 6208118BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.18" (30mm)
17mm Socket

SKU: 6208155BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.55" (39.4mm)
17mm Socket

SKU: 6208177BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.77" (45mm)
17mm Socket

SKU: 6208189BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.89" (48mm)
17mm Socket

SKU: 6208197BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.97" (50mm)
17mm Socket

SKU: 6208236BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 2.36" (60mm)
17mm Socket

SKU: 6208130BK

Conical Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.30" (33mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.50 Threads
Thread Length: 0.93" (23.6mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.50 Threads
Thread Length: 1.10" (28mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.50 Threads
Thread Length: 1.30" (33mm)
17mm Socket

Ball Seat Lug Bolt - Black Finish
14mm 1.50 Threads
Thread Length: 1.55" (39.4mm)
17mm Socket

Ball Seat Lug Bolt - 14mm Radius
14mm 1.50 Threads
Thread Length: 1.10" (28mm)
17mm Socket

Ball Seat Lug Bolt - 14mm Radius
14mm 1.50 Threads
Thread Length: 1.77" (45mm)
19mm Socket

Vehicle: 6 x 5.5" (139.7mm)
Wheel: 8 x 170mm / 8 x 180mm / 8 x 6.5" (165.1mm)
Studs: 14mm 1.5 Studs
108mm Center Bore

2 pc adapter available in 2" thickness only

SKU: 6828093

6 Spline Acorn Seat Lug Bolt
14mm 1.5 Thread
Thread Length: 0.93" (23.6mm)
Uses CWA Socket #6864

SKU: 6828110

6 Spline Acorn Seat Lug Bolt
14mm 1.5 Thread
Thread Length: 1.10" (28mm)
Uses CWA Socket #6864

SKU: 6828118

6 Spline Acorn Seat Lug Bolt
14mm 1.5 Thread
Thread Length: 1.18" (30mm)
Uses CWA Socket #6864

SKU: 6828125

6 Spline Acorn Seat Lug Bolt
14mm 1.5 Thread
Thread Length: 1.25" (31.8mm)
Uses CWA Socket #6864

SKU: 6828155

6 Spline Acorn Seat Lug Bolt
14mm 1.5 Thread
Thread Length: 1.55" (39.4mm)
Uses CWA Socket #6864

SKU: 6208102SH

Conical Seat Lug Bolt - Short Head
14mm 1.5 Thread
Thread Length: 1.02" (26mm)
17mm Socket

SKU: 6828093BK

6 Spline Acorn Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 0.93" (23.6mm)
Uses CWA Socket #6864

SKU: 6828110BK

6 Spline Acorn Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.10" (28mm)
Uses CWA Socket #6864

SKU: 6828125BK

6 Spline Acorn Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.25" (31.8mm)
Uses CWA Socket #6864

SKU: 6828155BK

6 Spline Acorn Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.55" (39.4mm)
Uses CWA Socket #6864

SKU: 6828118BK

6 Spline Acorn Seat Lug Bolt - Black Finish
14mm 1.5 Thread
Thread Length: 1.18" (30mm)
Uses CWA Socket #6864

Vehicle: 6 x 135mm
Wheel: 5 x 4.5" (114.3mm)
Available Studs: 12mm 1.5 or 14mm 1.5 Studs
87.1mm Center Bore

2 pc adapter available in 2" thickness only

Vehicle: 6 x 135mm
Wheel: 5 x 4.75" (120.65mm)
Available Studs: 12mm 1.5 or 14mm 1.5 Studs
87.1mm Center Bore

2 pc adapter available in 2" thickness only

Vehicle: 6 x 135mm
Wheel: 5 x 5.5" (139.7mm)
Available Studs: 1/2"-20 or 14mm 1.5
87.1mm Center Bore

2 pc adapter available in 2" thickness only

Vehicle: 6 x 5.5" (139.7mm)
Wheel: 5 x 4.5" (114.3mm)
Available Studs: 12mm 1.5 or 14mm 1.5 Studs
108mm Center Bore

2 pc adapter available in 2" thickness only

Vehicle: 6 x 5.5" (139.7mm)
Wheel: 5 x 4.75" (120.65mm)
Available Studs: 12mm 1.5 or 14mm 1.5 Studs
108mm Center Bore

2 pc adapter available in 2" thickness only

Vehicle: 6 x 5.5" (139.7mm)
Wheel: 5 x 5.5" (139.7mm)
Available Studs: 1/2"-20 or 14mm 1.5 Studs
108mm Center Bore

2 pc adapter available in 2" thickness only

All 5 x 4.5" Adapters

Easy Order Form for All 6 x 135mm VEHICLE Applications

Easy Order Form for All 5 x 120mm VEHICLE Applications

Vehicle: 8 x 200mm
Wheel: 8 x 200mm
14mm 1.5 Studs
146mm Center Bore

Easy Order Form for All 5 x 115mm VEHICLE Applications

Easy Order Form for All 5 x 4.5" VEHICLE Applications

Vehicle: 8 x 200mm
Wheel: 8 x 200mm
14mm 1.5 Studs
146mm Center Bore

Ball Seat Lug Bolt - Black Finish
14mm 1.5 Threads
Thread Length: 2.17" (55.12mm)
17mm Socket

Vehicle: 5 x 115mm
Wheel: 5 x 115mm

B = 1.25" Thickness
14mm 1.5 studs

Vehicle: 5 x 4.5" (114.3mm)
Wheel: 5 x 120mm

14mm 1.5 Studs
74mm Center Bore

Vehicle: 5 x 120mm
Wheel: 5 x 120mm

B = 1.25" Thickness

Vehicle: 5 x 115mm
Wheel: 5 x 115mm

X = 20mm Thickness

Hub and Wheel Centric Dodge Application

Vehicle: 5 x 115mm
Wheel: 5 x 115mm

A = 1" Thickness

Hub and Wheel Centric Dodge Application

Vehicle: 5 x 115mm
Wheel: 5 x 115mm

B = 1.25" Thickness

Hub and Wheel Centric Dodge Application

Vehicle: 5 x 120mm
Wheel: 5 x 120mm

X = 20mm Thickness

Hub and Wheel Centric Chevrolet Camaro / Cadillac / GMC Terrain

Vehicle: 5 x 120mm
Wheel: 5 x 120mm

B = 1.25" Thickness

Hub and Wheel Centric Volkswagen Application

Vehicle: 5 x 120mm
Wheel: 5 x 120mm

B = 1.25" Thickness

Hub and Wheel Centric Chevrolet Camaro / Cadillac / GMC Terrain

Vehicle: 5 x 4.5" (114.3mm)
Wheel: 5 x 4.5" (114.3mm)

14mm 1.5 Studs
70.5mm Hub Bore

Hub and Wheel Centric Mustang (2015-on) Application
